现代密码学
SHA-512算法

SHA-512算法

sha_1_bg

SHA-512属于sha2系列，工作在64位一个字上

  1. 消息填充(Padding)
  2. 将消息划分为 1024-bit block
  3. 初始化 8 个 64-bit 状态变量(H0～H7)
  4. 对每一个 block 进行 80 轮压缩(Compression Round)
  5. 输出最终的 512-bit digest

SHA-2基本都是这个流程，SHA3可能会不一样

1. 消息填充

SHA-512的填充长度是最长的，1024bit数据记一块数据,前面md5,sha1,sha256都是512bit一组

  • 原始消息后加上 0x80(即 1 bit)
  • 再补若干 0 bit，直至最后 128 bit 留给“消息长度”
  • 最后追加一个 128 bit 的 big-endian 数，表示消息的 bit 长
message || 1 || 0...0 || (message_length_in_bits on 128 bits)

这个填充也就是标准流程了

2. 初始化hash值

SHA-512 使用 8 个 64-bit 常量作为初始状态
这个长度也是最长的，汇编可能会使用多次左移运算来拼接

H0 = 0x6a09e667f3bcc908
H1 = 0xbb67ae8584caa73b
H2 = 0x3c6ef372fe94f82b
H3 = 0xa54ff53a5f1d36f1
H4 = 0x510e527fade682d1
H5 = 0x9b05688c2b3e6c1f
H6 = 0x1f83d9abfb41bd6b
H7 = 0x5be0cd19137e2179

3. 压缩函数

SHA-512 每个 block 需要做 80 轮（round） 计算

  • 一个 64-bit 的 round constant: K[i]
  • 一个 64-bit 的消息调度字: W[i]

3.1 σ 函数（小 sigma）

σ0(x) = ROTR(x,1)  ^ ROTR(x,8)  ^ (x >> 7)
σ1(x) = ROTR(x,19) ^ ROTR(x,61) ^ (x >> 6)

3.2 Σ 函数（大 Sigma）

Σ0(x) = ROTR(x,28) ^ ROTR(x,34) ^ ROTR(x,39)
Σ1(x) = ROTR(x,14) ^ ROTR(x,18) ^ ROTR(x,41)

3.3 CH 和 MAJ

布尔函数（选择、主元）：

Ch(x,y,z)  = (x & y) ^ (~x & z)
Maj(x,y,z) = (x & y) ^ (x & z) ^ (y & z)

到这我已经看不懂了，不过trace一下看看日志或者看实现出来的代码理解理解就行，咱也不是密码学家

4. 消息调度（Message Schedule）

SHA-512 的 W 数组大小为 80 个 64-bit word
初始化前 16 个:

for i = 0..15:
    W[i] = block[i]

后64个

for i = 16..79:
    W[i] = σ1(W[i-2]) + W[i-7] + σ0(W[i-15]) + W[i-16]

全部对 2^64 取模(自然溢出即可)

5. 每轮更新阶段变量(a,b,c,d,e,f,g,h)

初始状态

a=H0
b=H1
c=H2
d=H3
e=H4
f=H5
g=H6
h=H7

每轮计算

T1 = h + Σ1(e) + Ch(e,f,g) + K[i] + W[i]
T2 = Σ0(a) + Maj(a,b,c)

h = g
g = f
f = e
e = d + T1
d = c
c = b
b = a
a = T1 + T2

6. 最终结果回写

H0 = H0 + a
...
H7 = H7 + h

最终输出 H0||H1||…||H7 即为 512-bit 哈希

总结

对于这个东西，我们尽可能记住初始化数值，k值，不过各位根据最终结果的长度进行判断也差不多了，然后就是打trace，frida调试
可能会对补充进行魔改(对于小厂肯定是倍数，如果不是倍数难度不亚于自己写一个hash)，轮数魔改(80到160或者40，对于小厂肯定是倍数，如果不是倍数魔改难度太大) 代码是我抄了一份老外的

#include <stdio.h>
#include <stdint.h>
#include <string.h>
#include <stdlib.h>

// Circular right shift
#define ROTR(x, n) ((x >> n) | (x << (64 - n)))

// SHA-512 functions
#define Ch(x, y, z) ((x & y) ^ ((~x) & z))
#define Maj(x, y, z) ((x & y) ^ (x & z) ^ (y & z))
#define Sigma0(x) (ROTR(x, 28) ^ ROTR(x, 34) ^ ROTR(x, 39))
#define Sigma1(x) (ROTR(x, 14) ^ ROTR(x, 18) ^ ROTR(x, 41))
#define sigma0(x) (ROTR(x, 1) ^ ROTR(x, 8) ^ (x >> 7))
#define sigma1(x) (ROTR(x, 19) ^ ROTR(x, 61) ^ (x >> 6))

uint64_t k[] =
{
    0x428a2f98d728ae22, 0x7137449123ef65cd, 0xb5c0fbcfec4d3b2f, 0xe9b5dba58189dbbc,
    0x3956c25bf348b538, 0x59f111f1b605d019, 0x923f82a4af194f9b, 0xab1c5ed5da6d8118,
    0xd807aa98a3030242, 0x12835b0145706fbe, 0x243185be4ee4b28c, 0x550c7dc3d5ffb4e2,
    0x72be5d74f27b896f, 0x80deb1fe3b1696b1, 0x9bdc06a725c71235, 0xc19bf174cf692694,
    0xe49b69c19ef14ad2, 0xefbe4786384f25e3, 0x0fc19dc68b8cd5b5, 0x240ca1cc77ac9c65,
    0x2de92c6f592b0275, 0x4a7484aa6ea6e483, 0x5cb0a9dcbd41fbd4, 0x76f988da831153b5,
    0x983e5152ee66dfab, 0xa831c66d2db43210, 0xb00327c898fb213f, 0xbf597fc7beef0ee4,
    0xc6e00bf33da88fc2, 0xd5a79147930aa725, 0x06ca6351e003826f, 0x142929670a0e6e70,
    0x27b70a8546d22ffc, 0x2e1b21385c26c926, 0x4d2c6dfc5ac42aed, 0x53380d139d95b3df,
    0x650a73548baf63de, 0x766a0abb3c77b2a8, 0x81c2c92e47edaee6, 0x92722c851482353b,
    0xa2bfe8a14cf10364, 0xa81a664bbc423001, 0xc24b8b70d0f89791, 0xc76c51a30654be30,
    0xd192e819d6ef5218, 0xd69906245565a910, 0xf40e35855771202a, 0x106aa07032bbd1b8,
    0x19a4c116b8d2d0c8, 0x1e376c085141ab53, 0x2748774cdf8eeb99, 0x34b0bcb5e19b48a8,
    0x391c0cb3c5c95a63, 0x4ed8aa4ae3418acb, 0x5b9cca4f7763e373, 0x682e6ff3d6b2b8a3,
    0x748f82ee5defb2fc, 0x78a5636f43172f60, 0x84c87814a1f0ab72, 0x8cc702081a6439ec,
    0x90befffa23631e28, 0xa4506cebde82bde9, 0xbef9a3f7b2c67915, 0xc67178f2e372532b,
    0xca273eceea26619c, 0xd186b8c721c0c207, 0xeada7dd6cde0eb1e, 0xf57d4f7fee6ed178,
    0x06f067aa72176fba, 0x0a637dc5a2c898a6, 0x113f9804bef90dae, 0x1b710b35131c471b,
    0x28db77f523047d84, 0x32caab7b40c72493, 0x3c9ebe0a15c9bebc, 0x431d67c49c100d4c,
    0x4cc5d4becb3e42b6, 0x597f299cfc657e2a, 0x5fcb6fab3ad6faec, 0x6c44198c4a475817
};


// Initial hash values
uint64_t H[] =
{
    0x6a09e667f3bcc908, 0xbb67ae8584caa73b, 0x3c6ef372fe94f82b, 0xa54ff53a5f1d36f1,
    0x510e527fade682d1, 0x9b05688c2b3e6c1f, 0x1f83d9abfb41bd6b, 0x5be0cd19137e2179
};


uint64_t W[80];

//  compression function
void sha512_compress(uint64_t *state, const uint8_t *block)
{
    int t;
    uint64_t temp1, temp2, maj, ch;

    // Prepare message
    for (t = 0; t < 16; t++)
	{
        W[t] = ((uint64_t)block[t * 8] << 56) | ((uint64_t)block[t * 8 + 1] << 48) |
               ((uint64_t)block[t * 8 + 2] << 40) | ((uint64_t)block[t * 8 + 3] << 32) |
               ((uint64_t)block[t * 8 + 4] << 24) | ((uint64_t)block[t * 8 + 5] << 16) |
               ((uint64_t)block[t * 8 + 6] << 8) | ((uint64_t)block[t * 8 + 7]);
    }

    for (t = 16; t < 80; t++)
	{
        W[t] = sigma1(W[t - 2]) + W[t - 7] + sigma0(W[t - 15]) + W[t - 16];
    }

    // Initialize working variables
    uint64_t a = state[0];
    uint64_t b = state[1];
    uint64_t c = state[2];
    uint64_t d = state[3];
    uint64_t e = state[4];
    uint64_t f = state[5];
    uint64_t g = state[6];
    uint64_t h = state[7];

    // Main loop
    for (t = 0; t < 80; t++)
	{
        temp1 = h + Sigma1(e) + Ch(e, f, g) + k[t] + W[t];
        temp2 = Sigma0(a) + Maj(a, b, c);
        h = g;
        g = f;
        f = e;
        e = d + temp1;
        d = c;
        c = b;
        b = a;
        a = temp1 + temp2;
    }

    // change hash values
    state[0] += a;
    state[1] += b;
    state[2] += c;
    state[3] += d;
    state[4] += e;
    state[5] += f;
    state[6] += g;
    state[7] += h;
}

//  final hash calculation
void sha512(const char *message, int round)
{
    uint8_t block[128];
    uint64_t bitlen = strlen(message) * 8;
    uint64_t state[8];
    int i, len, offset;

    // Initialize hash values
    for (i = 0; i < 8; i++)
	{
        state[i] = H[i];
    }

    // Process the message in blocks
    len = strlen(message);
    offset = 0;

    while (offset < len)
	{
        int block_size = (len - offset < 128) ? len - offset : 128;

        // Copy the block
        memset(block, 0, 128);
        memcpy(block, message + offset, block_size);

        // Padding
        if (block_size < 128)
		{
            block[block_size] = 0x80;
            if (block_size < 112)
			{
                // Append the bit length to the end of the message
                for (i = 0; i < 8; i++)
				{
                    block[112 + i] = (bitlen >> ((7 - i) * 8)) & 0xFF;
                }
            }
        }
        // Process the block
        sha512_compress(state, block);

        // Move to the next block
        offset += block_size;
    }

    // Display intermediate round values
    printf("values for round %d:\n", round);
    for (i = 0; i < round; i++)
	{
        printf("H[%d] = %016lx\n", i, state[i]);
    }

    // Display the final hash value
    printf("Final hash value:\n");
    for (i = 0; i < round; i++)
	{
        printf("%016lx", state[i]);
    }
    printf("\n");
}


int main() {
    char message[1024];
    int round;

    // Get input from the user
    printf("Enter the text: ");
    fgets(message, sizeof(message), stdin);

    // Remove the newline character
    message[strcspn(message, "\n")] = '\0';

    printf("Enter the round number: ");
    scanf("%d", &round);

    // Validate round number
    if (round < 0 || round >= 80)
	{
        printf("Invalid round number. It should be in the range [0, 79].\n");
        // Exit with an error code
        return 1;
    }

    sha512(message, round);

    return 0;
}
